Product Series:Heavy Load Milling Spindle

Product Number:DGZX-28010/42-KFHWVJLS

It is mainly applied to machining of machine tool of high speed CNC machiningcenter, and it is suitable to machining of large-scale mold, auto parts andaeronautical parts, etc.

1.Highprecision: The total run-out of internal conical surface at shaft end of electric spindle of machining center is≤0.001 mm; the spindle vibration is ≤1.0 mm/s;HSK, BT handle is adopted; and it has incomparable high precision.

2.Highrevolution: The maximum revolution of electric spindle of machining centerreaches as high as 20,000 rpm, which provides powerful support for thehigh-efficiency and high-precision machining of the high speed machiningcenter.

3.Largetorque: The low speed large torque of electric spindle of the machining centermakes heavy cutting during rough machining of machine tool become possible,which improves the machining efficiency of product.

4.Highconfiguration: Temperature probe, displacement sensor, vibration sensor,proximity switch and closed-loop control encoder is optional for the electricspindle of machining center, and bearing of international famous brand isadopted.

5.Goodextensibility and high compatibility: The electric spindle of machining centerhas good compatibility, and it can be widely applied to the high speedmachining center for machining of various parts.


Spindle   ModelDGZX-28010/42-KFHWVJLS
Rated Speed   (rpm)2000
Maximum Speed   (rpm)10000
(S1)Rated   Power (kW)42
(S1)Rated   Torque (Nm)203
 Maximum Current (A)380V-119A
(S1)Rated   Electric (A)380V-79.SA
Motor TypeAsynchronous   Motor
Bearing TypeHybrid Ball Bearings
Bearings   LubricationOil-Air
 Tool InterfaceHSK-A100
Tool Change   UnitHydraulic
