DQZBP-80／8_3-Finger pneumatic paralell Grippers_Automated fixture (outside)_Guangzhou Haozhi Industrial Co., LTD

Consultation

Product Series：3-Finger pneumatic paralell Grippers

Product Number：DQZBP-80／8

Robot terminal actuator by Haozhi.High precision,Low weight,High clamping force,Faster, more flexible and smarter.

1. With a clamped wedge structure, the clamping force is large.

2. Solid T-rail design ensuring accurate clamping.

3. Lightweight design, compact, simple, small sized.

4. Full hardening treatment, giving a long life and stable clamping force.

5. Reliable performance withstanding 1-million impact testing.

6. Two-sided magnetic switch slot design is convenient for customers to operate.

Product model	DQZBP-80/8
Clamping/release force (N)	1100/1100
Repeated positioning accuracy (mm)	0.01
Rated working air pressure (Mpa)	0.6
Air fingering stroke (mm)	8
Clamping and releasing time (s)	0.1
The Weight (Kg )	0.93
