Product Series：2-Finger pneumatic angular Grippers

Product Number：Connecting rod type DQZAJ02-26-3／30

Robot terminal actuator by Haozhi.High precision,Low weight,High clamping force,Faster, more flexible and smarter.

1. Hardened mating surface offers an increased service life.

2. With thin and light design, it saves weight and installation space.

3. High repeated positioning accuracy.

Product model	DQZAJ02-26-3／30
Clamping torque (Nm)	2
Repeated positioning accuracy (mm)	0.05
Rated working air pressure (Mpa)	0.6
Air fingering opening angle (°)	30
Angle per finger when clamping (°)	2
Clamping and releasing time (s)	0.03/0.06
