Product Series：2-Finger pneumatic angular Grippers

Product Number：Enhanced CAM type DQZAJ03-125-3／15

Robot terminal actuator by Haozhi.High precision,Low weight,High clamping force,Faster, more flexible and smarter.

1. Hardened mating surface offers an increased service life.

2. Enhanced cam can grasp heavier goods.

3. High repeated positioning accuracy.

技术参数

序号	项目	标准值

Product model	DQZAJ03-125-3／15
Clamping torque (Nm)	57
Repeated positioning accuracy (mm)	0.02
Rated working air pressure (Mpa)	0.6
Air fingering opening angle (°)	15
Angle per finger when clamping (°)	3
Clamping and releasing time (s)	0.14/0.14
