GUANGZHOU HAOZHI INDUSTRIAL CO., LTD.

Consultation

Product Series:Quick-change System

Product Number:Slider type DKH01-050-R/M

Quick-change module takes 0.1s to clamp and loosen.Significantly improve production efficiency, and flexibility in handling and assembly.

1. With slider locking structure, the tapered hole is self-centering and clamped.

2. High repeated positioning accuracy.

3. Small sized, light, reliable clamping.

4. With self-locking in case of gas is disconnected,

even if accidental gas is disconnected, the clamped items will not fall.


Product   model DKH01-050-R/M
Maximum   clamping weight (Kg)60
Repeated   positioning accuracy (mm)0.015
Rated working   air pressure (Mpa)0.6
Maximum   separation distance at clamping (mm)0.6
Air hole16-G1/8
The Weight   (Kg )2.1
