Product Series：Machining center series

Product Number：Super Motor Spindle-DGZX-15018/20-BBT

This Super Motor spindle integrates advanced dual-winding technology to deliver strong low-speed torque and efficient high-speed performance up to 18,000 rpm. Designed with a BBT40 interface and Φ150 mm structure, it provides stable, precise, and versatile machining performance for a wide range of industrial applications


技术参数
序号 项目 标准值
Model: DGZX-15018/20-BBT

Low windingHigh winding
DiameterΦ150mm
Tool interfaceBBT40
Bearings LubricationGrease
Motor systemAsynchronous
The highest speed9,000rpm18,000rpm
Voltage175V175V
Rated power (S1-100%)20kW20kW
Rated torque (S1-100%)53N.m28N.m
Rated power (S6-40%)24kW24kW
Rated torque (S6-40%)64N.m34N.m
Spindle coolantWater (recommended)
Tool outer coolant(Ring spray)Water/Oil/Oil mist/Air
Tool ChangeHydraulic
Motor temperature sensorKTY84-130、PTC
EncoderSin/cos,1VPP
Tool clamping monitor sensor24V、PNP、Normally Open
Clamping Power7000-9000N
