As a kind of highly precise Swiss-type motorized spindle， the max. speed could reach 8000 rpm，this product can be configured with φ10-φ16 collet，and the spindle is configured with 1.5 kW asynchronous motor with rated and max. torsion of 3.7 Nm and 11.5 Nm respectively.
And used for finish turning and used for finish turning and heavy cutting of steel parts,nonferrous metals as well as installation of Swiss-type CNC composite machine tool.And is mainly applied to processing in such fields as hardware, clock, lamps, etc.
1. Application of high-performance heavy load bearing:
Through optimizing bearing application and with a high rotation precision, this product is applicable to high-speed cutting of nonferrous metals in clock and lamp field and could ensure excellent appearance texture. The roughness and roundness of cut sample could be Ra≤0.4μm and ≤2μm respectively.
2. High-performance asynchronous motor:
Rated power: 1.5 kW
Rated torque: 3.7 Nm
Max. speed: 8000 rpm
Max. torque: 11.5 Nm
3. Diverse configuration:
Products can be customized according to different needs of customers.
|Motor type||3-phase AC asynchronous induction motor|
|Max. speed (rpm)||8000|
|Max. current (A)||8.6|
|Max. torque (Nm)||11.5|
|Rated voltage (V)||380|
|Rated power (S1/100%) (kW)||1.5|
|Rated torque (S1/100%) (Nm)||3.7|
|Lubrication form||Oil grease|
|Run-out of standard bar at 500mm||≤0.02|
|through-hole diameter (mm)||φ12|
|Encoder||Square wave encoder|
|Installation form||Horizontal installation|
|Applicable CNC system：Siemens, Fanuc, Huazhong Numeral Control, GSK, Baoyuan etc.|
